Straddle Assembly Torque Rod Bush to suit Kenworth 200-400 Series

Straddle Assembly Torque Rod Bush to suit Kenworth 200-400 Series

Australian Truck & Trailer Parts designed Straddle Assembly Torque Rod Bush to suit Kenworth 2 Inch 49/64 Straddle Assembly. Replaces Kenworth 227720: Airglide 100, Glide Ride, 4 Bag Airglide, ‘Big 6” for use in stabiliser bar.Kenworth 836940: Airglide 200/400/460/69

$126.50

46 in stock (can be backordered)

SKU 09.1651.18 Categories , , , ,

Description

2 Inch 49/64 Straddle Assembly Replaces
Kenworth 227720: Airglide 100,  Glide Ride, 4 Bag Airglide, ‘Big 6” for use in stabiliser bar.
Kenworth 836940: Airglide 200/400/460/690
International 1693061C1:
Corporate Four Springs, 8100/9200
Single Axle, Corporate Air Hendrickson 44695
ATRO: TS38000 Torque Rod Bushing, TS59-22400 Straddle Bushing (High Articulation), SK70380
Straddle Pin 360 Degrees Rotation, 11 Degrees lateral

Dimensions:
SHAFT HOLE DIA.= 18MM
BOSS O.D = 69.87MM
BOSS WIDTH = 61 MM
SHAFT HOLE TO HOLE = 111.0 MM
SHAFT ACROSS FLATS = 29MM

Additional information

Weight 2 kg
