Straddle Assembly Torque Rod Bush to suit Mack

Straddle Assembly Torque Rod Bush to suit Mack

Australian Truck & Trailer Parts Designed Tapered Suspension Torque Rod Bush to Suit Mack, Neway  and Rockwell Suspensions

Replaces: Mack 380F29407M   Mack Part No: 98.38QF29407M, Neway AD. 252-11

$336.05

6 in stock (can be backordered)

SKU 09.1517.28 Categories , , , ,

Description

Australian Truck & Trailer  Parts Designed  Tapered Suspension Torque Rod Bush to suit Mack, Neway  and Rockwell Suspensions
Replaces: Mack 380F29407M   Mack Part No: 98.38QF29407M, Neway AD. 252-11

Includes;
1. 71.058.10.125 Bolt(1)
2. 70.111.10 Washer (1)
3. 09.1520.26 Washer (1)
4. 09.1517.05 Boss Outer (1)
5. 09.1517.26 Washer (2)
6. 09.1505.09 Bush-Red (2)
7. 09.1517.23 Shaft (1)
8. 38.130.085 Circlip (1)
9. 71.611.20 Nyloc Nut(1)

Dimensions
SHAFT HOLE DIA=203.5MM
BOSS O.D=88.8MM
BOSS WIDTH=68.0MM
SHAFT THREAD=1-1/4”12 TPIUNF
SHAFT TAPER LENGTH= 78.4MM
SHAFT TAPER DIA.= 45.0MM

Additional information

Weight 3.88 kg
